Java 20: Foreign Function & Memory API Refinement
Ravinder··6 min read
JavaForeign Function APIPattern MatchingJava 20

Java 20: FFM API Refinement and Pattern Matching Evolution
Java 20 (March 2023) continued evolution of FFM API and brought pattern matching closer to finalization. It's a bridging release before Java 21 LTS.
1. Foreign Function & Memory API (Preview 3)
Enhanced APIs for safer native code integration.
// Calling native C functions safely
import java.lang.foreign.*;
public class NativeCodeInterop {
// Improved FFM API
public static void main(String[] args) throws Throwable {
Linker linker = Linker.nativeLinker();
SymbolLookup stdlib = linker.defaultLookup();
// Looking up strlen function
MemorySegment strlenAddress = stdlib.find("strlen").get();
// Function descriptor and handle
FunctionDescriptor strlen = FunctionDescriptor.of(
ValueLayout.JAVA_LONG, // return type
ValueLayout.ADDRESS // parameter
);
MethodHandle strlenHandle = linker.downcallHandle(
strlenAddress,
strlen
);
// Calling native function
Arena arena = Arena.ofAuto();
MemorySegment nativeString = arena.allocateUtf8String("Hello World");
long length = (long) strlenHandle.invoke(nativeString);
System.out.println("String length: " + length); // 11
}
// Creating callbacks for C functions
public static class CallbackExample {
public static void registerCallback() throws Throwable {
// Java callback that can be called from native code
int javaCallback(int x) {
return x * 2;
}
// Create native function pointer to Java method
// Advanced usage for library integration
}
}
}2. Pattern Matching for switch (Preview 4)
Pattern matching continues evolving toward fuller support.
// More sophisticated pattern matching
public sealed class Shape {}
public record Circle(double radius) extends Shape {}
public record Rectangle(double width, double height) extends Shape {}
public record Line(double length) extends Shape {}
public String describeShape(Shape shape) {
return switch (shape) {
case Circle(double r) when r > 10 -> "Large circle: " + r;
case Circle(double r) -> "Small circle: " + r;
case Rectangle(double w, double h) when w == h ->
"Square: " + w;
case Rectangle(double w, double h) ->
"Rectangle: " + w + "x" + h;
case Line(double len) -> "Line: " + len;
};
}
// Complex nested patterns
record Person(String name, Address address) {}
record Address(String city, String country) {}
public boolean isLocalResident(Object obj) {
return obj instanceof Person(var name, Address(var city, "USA")) &&
city.equals("New York");
}3. Record Patterns in instanceof
Destructuring records in type checks.
// Record pattern destructuring
public record UserProfile(String username, int age, String email) {}
public void processUser(Object user) {
if (user instanceof UserProfile(String name, int age, _)) {
System.out.println(name + " is " + age + " years old");
}
}
// Practical example
public void validateEmail(Object obj) {
if (obj instanceof UserProfile(_, _, String email) &&
email.contains("@")) {
System.out.println("Valid email");
}
}4. Virtual Threads and Structured Concurrency (Better Preview)
Refinements to Project Loom features.
// Virtual threads improvements
public class EnhancedVirtualThreads {
public static void main(String[] args) throws Exception {
int NUM_TASKS = 100_000;
List<String> results = new ArrayList<>();
// Better structured concurrency
try (var scope = new StructuredTaskScope.ShutdownOnSuccess<String>()) {
for (int i = 0; i < NUM_TASKS; i++) {
scope.fork(() -> performTask());
}
String firstSuccess = scope.join(); // Wait for first success
System.out.println("Got result: " + firstSuccess);
}
}
static String performTask() {
// Work runs on virtual thread
return "Result";
}
}5. Scoped Values (Incubating)
Thread-local replacements for virtual thread era.
// Scoped values - cleaner than ThreadLocal
import java.lang.ScopedValue;
final static ScopedValue<String> REQUEST_ID = ScopedValue.newInstance();
final static ScopedValue<User> CURRENT_USER = ScopedValue.newInstance();
public void handleRequest(String requestId, User user) {
ScopedValue.callWhere(REQUEST_ID, requestId,
() -> ScopedValue.callWhere(CURRENT_USER, user,
() -> processRequest()
)
);
}
private void processRequest() {
// Access scoped values anywhere in call chain
String reqId = REQUEST_ID.get();
User usr = CURRENT_USER.get();
System.out.println("Processing: " + reqId + " for " + usr.name());
}
// Key difference from ThreadLocal:
// - Works perfectly with virtual threads
// - No cleanup needed
// - No memory leaks
// - Better performance6. Garbage Collection Updates
Improvements to GC algorithms.
# G1GC improvements
java -XX:+UseG1GC \
-XX:MaxGCPauseMillis=50 \
-XX:+ParallelRefProcEnabled \
MyApp
# ZGC improvements (sub-millisecond pauses)
java -XX:+UnlockExperimentalVMOptions \
-XX:+UseZGC \
-XX:ZCollectionInterval=120 \
MyApp
# Shenandoah improvements
java -XX:+UnlockExperimentalVMOptions \
-XX:+UseShenandoahGC \
MyAppDeveloper Impact
Positive:
- FFM API Stability: Getting closer to finalization
- Pattern Matching: Richer pattern support
- Virtual Thread Polish: Better preview implementation
- Scoped Values: ThreadLocal alternative
Challenges:
- Still Preview Features: Not yet finalized
- Short Support: Non-LTS release
- Learning Curve: Multiple preview features in one release
Pros and Cons
Pros ✅
- FFM Refinement: Native interop getting more powerful
- Pattern Matching: More expressive pattern support
- Virtual Thread Stability: Getting production-ready
- Scoped Values: Better alternative to ThreadLocal
- GC Improvements: Multiple GC algorithms improved
Cons ❌
- Preview Status: May still change before finalization
- No LTS: 6-month support only
- Learning Curve: Complex features
- Tooling: Still catching up with features
Practical Example
// Modern web service with Java 20
public class RestAPI {
static final ScopedValue<RequestContext> CONTEXT =
ScopedValue.newInstance();
public void handleRequest(HttpExchange exchange) throws IOException {
var context = new RequestContext(
UUID.randomUUID().toString(),
exchange.getRemoteAddress().getHostName()
);
ScopedValue.callWhere(CONTEXT, context, () -> {
String path = exchange.getRequestURI().getPath();
String response = switch (path) {
case "/users" -> handleUsers();
case "/orders" -> handleOrders();
default -> "{\"error\":\"Not found\"}";
};
exchange.sendResponseHeaders(200, response.length());
exchange.getResponseBody().write(response.getBytes());
exchange.close();
});
}
private String handleUsers() {
RequestContext ctx = CONTEXT.get();
logRequest("Fetching users for " + ctx.clientIP);
return "[{\"id\":1,\"name\":\"John\"}]";
}
private String handleOrders() {
RequestContext ctx = CONTEXT.get();
logRequest("Fetching orders for " + ctx.clientIP);
return "[{\"id\":1,\"total\":99.99}]";
}
private void logRequest(String msg) {
RequestContext ctx = CONTEXT.get();
System.out.println("[" + ctx.requestId + "] " + msg);
}
}
record RequestContext(String requestId, String clientIP) {}Conclusion
Java 20 is a refinement release preparing the platform for Java 21 LTS. The FFM API, pattern matching, and virtual threads are all converging toward finalization. This is an important stepping stone to Java 21 where these features become standard.
Key Points:
- Understand preview features well
- Java 20 bridges to Java 21 LTS
- Virtual threads will transform concurrent programming
- Plan to migrate to Java 21 LTS in September 2023
